Nissan Sentra Service Manual: Wiring diagram

Power window system

Wiring Diagram







Basic inspection


Power window main switch
Reference Value TERMINAL LAYOUT PHYSICAL VALUES MAIN POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH Fail Safe FAIL-SAFE CONTROL Switches to fail-safe control when malfunction is detected i ...

Basic inspection
...
