Nissan Sentra Owners Manual: Supplemental air bag warning labels
- SRS Front Air Bag Warning Labels
Warning labels about the supplemental frontimpact air bag system are placed in the vehicle as shown in the illustration.
Precautions on supplemental restraint system
This Supplemental Restraint System (SRS) section
contains important information concerning
the following systems:
Driver and passenger supplemental frontimpact
air bag (NISSAN Advanced Air Bag ...
Supplemental air bag warning light
The supplemental air bag warning light,
displaying in the instrument panel,
monitors
the circuits for the air bag systems, pretensioners
and all related wiring.
When the ignition switch i ...
