Toyota Camry Owner's Manual (2023): Parking brake
Operating instructions
To set the parking brake, fully depress the parking brake pedal with your left foot while depressing the brake pedal with your right foot.
(Depressing the pedal again releases the parking brake.)
â– Parking brake engaged warning buzzer
A buzzer will sound if the vehicle is driven with the parking brake engaged.
"Release Parking Brake" is displayed on the multi-information display.
NOTICE
â– Before driving
Fully release the parking brake.
Driving the vehicle with the parking brake set will lead to brake components overheating, which may affect braking performance and increase brake wear.
Turn signal lever
Operating instructions
Right turn
Lane change to the right (move
the lever partway and release
it)
The right hand signals will flash 3
times.
Lane change to the left (move
the lever ...
Electric parking brake
A mode can be selected from the following modes.
Automatic mode
The parking brake is set or released automatically according to the
shift lever operation.
Even when in automatic mode, the parkin ...
Other materials:
B0029 Side curtain air bag module RH
Description
DTC B0029 RH SIDE CURTAIN AIR BAG MODULE
The RH side curtain air bag module is wired to the air bag diagnosis sensor
unit. The air bag diagnosis sensor
unit will monitor for opens and shorts in detected lines to the RH side curtain
air bag module.
PART LOCATION
Refer to SRC-5, ...
Brake fluid
â– Checking fluid level
The brake fluid level should be
between the "MAX" and "MIN"
lines on the tank.
"MAX"
"MIN"
â– Adding fluid
Make sure to check the fluid type and prepare the necessary item.
â– Brake fluid can absorb moisture from the air
Excess moisture in the brake fluid ...
Engine compartment check locations
MRA8DE engine
Engine oil filler cap
Brake and clutch (if so equipped) fluid
reservoir
Air cleaner
Battery
Fuse/fusible link box
Engine coolant reservoir
Radiator cap
Engine oil dipstick
Drive belt location
Windshield-washer fluid reservoir
...
